7.0 inch TFT LCD MODULE CT070BQU38
- View full size
Products Category
| Size: | 7.0 inch TFT LCD MODULE |
| Part No.: | CT070BQU38 |
| Resolution: | 1024 (RGB) x 600 |
| Viewing Angle: | 6 O'clock |
| Module size(mm): | 164.90(W) x 100.00 (H) x 5.7(T) |
| Active Area(mm): | 154.08(W) x 85.92(H) |
| Display Type: | Normally White,Transmissive 40PIN |
| Driving IC: | / |
| Interface: | LVDS Interface |
| Backlight: | LED backlight |
| Brightness (cd/m2) | 500 |
| Contrast Ratio: | 800 |
| Touch Panel: | Optional with resistive and capacitive touch |
